Hot Feed Rubber Extruder
Hot feed rubber extruder is mainly used to extrude unvulcanized rubber products, such as inner tube, tire tread, rubber tube, etc.
Product features
1.The machine is a heat-feed and single screw extruder with adjustable rotating speed.
2.The machine can extrude different shapes of rubber products with the changing of extruding dies.
3.Jacketed type barrel can be cooled for cooling the rubbers effectively.
4.Smoothly running and high output.
Main technical specification of hot feed rubber extruder | ||||||
Model | XJ-115(120) | XJ-120 | XJ-150 | XJ-200 | XJ-250 | XJ-300 |
L/D ratio | 4.6 | 6 | 4.6 or 6.10 | 5 or 6 | 4.5 or 6 | 4.5 |
Motor power (kw) | 22 or 30 | 30 or 37 | 55 or 75 | 75 or 90 | 110 | 160 |
Production capacity (kg/h) | 400 | 450 | 1050 | 1700 | 3300 | 4000 |
Weight (ton) | 2.2 | 2.8 | 4.5 | 6 | 8.5 | 11 |
Length*Width*Height (mm) | 2100*550*1388 | 2950*650*1350 | 3200/3800*1100*1300 | 4400*1400*1600 | 5000*1450*1600 | 4500*1500*1600 |
