Bead Wire Grommet Forming Machine
Bead wire grommet forming machine is mainly used for wingding up square section bead of lawn& garden tire, Semi-steel tire, OTR tire huge OTR tire. The machine can wind 2 to 6 beads at one time.
Bead wire grommet machine is composed of wire reel stand, rubber extruder, bead wire cooling stand, bead wire pre-storing stand, bead wire pre-bending stand and bead wire ring forming stand.
This machine is fully automatic during the whole bead wire ring forming process, it is auto-feeding, auto-counting turns and auto-ejecting.
This machine is with functional design and tension device, avoiding bead wire loosing and deviating from guide roller.
Bead Wire Pre-Storing Stand is available for the purpose of continuing forming while wire reels are finished.
Technical Specifications of Bead wire grommet forming machine (Square Section Bead Winding Line) | ||||||
Lawn& Garden Tire | Semi-steel Tire | OTR Tire | Huge OTR Tire | |||
Bead Dia. range | 4''-10'' | 12''-20'' | 20''-40'' | 26''-56'' | ||
Bead inner perimeter tolerance | ±0.35mm | ±0.35mm | ±0.5mm | ±0.5mm | ||
Bead thickness tolerance | ±0.5mm | ±0.5mm | ±0.8mm | ±0.8mm | ||
Bead overlap length | 100±10mm | 100±10mm | 300±10mm | 300±10mm | ||
Bead overlap length accuracy | ±2mm | ±2mm | ±2mm | ±2mm | ||
Bead Dia. | ~0.96mm | ~0.96mm | ~1.55mm | ~1.55mm | ||
Steel wire let off working station | 8-24 working stations | 8-24 working stations | 8-24 working stations | 8-24 working stations | ||
Extruder model | 65/90 | 65/90 | 65/90 | 65/90 | ||
Extruder power | 11Kw/30Kw | 11Kw/30Kw | 11Kw/30Kw | 11Kw/30Kw | ||
Screw L/D | 1: 12/ 1: 14 | 1: 12/ 1: 14 | 1: 12/ 1: 14 | 1: 12/1: 14 | ||
Wire storing length | 30m | 30m | 30m | 30m | ||
Winding linear speed (Max.) | 60m/min | 80m/min | 80m/min | 80m/min | ||
